60m (C30 is two capacitors in parallel)
Qty Value Description Component numbers
1 39pF Label “390” C5
1 22pF Label “220” C8
1 30pF Label “300” C30 (C30 is two capacitors in parallel)
1 56pF Label “560” C30 (C30 is two capacitors in parallel)
2 680pF Label “681" C27, 28
2 1200pF Label “122” C25, 26
40m (no C8 capacitor)
Qty Value Description Component numbers
1 39pF Label “390” C5
1 56pF Label “560” C30
2 270pF Label “271" C27, 28
2 680pF Label “681” C25, 26
30m (no C8 capacitor)
Qty Value Description Component numbers
1 22pF Label “220” C5
1 30pF Label “300” C30
2 270pF Label “271" C27, 28
2 560pF Label “561” C25, 26
20m (no C5 or C8 capacitors)
Qty Value Description Component numbers
1 30pF Label “300” C30
2 180pF Label “181" C27, 28
2 390pF Label “391” C25, 26
17m (no C5 or C8 capacitors)
Qty Value Description Component numbers
1 30pF Label “300” C30
2 100pF Label “101" C27, 28
2 270pF Label “271” C25, 26
Semiconductors
Qty Description Component numbers
5 SMD D1, 2, 4, 5, 6
1 1N5819 diode D33 (was previously D3)
7
