QSC K8.2 Application Guide

K.2 APPLICATION GUIDE— Solo/Duo Musicians 5
SOLO PERFORMER
BUSKING / COCKTAIL PARTY GIG
A solo singer/instrumentalist can make use of the mixer built into each K.2 loudspeaker. For a small gig busking or playing
a cocktail party this performer uses a single K8.2, plugging the vocal mic into Input A and the acoustic guitar’s piezo pickup
system into Input B, plus another K8.2 as an optional small wedge monitor. If AC mains power is unavailable, the very low
current draw of the loudspeaker makes it possible to run for a few hours from a suitable battery and inverter system.
The Acoustic Guitar / Vox preset is optimized for using a vocal mic on Input A and an acoustic guitar with a piezo pickup on
Input B.
TECH REQUIREMENTS:
One vocal mic
One acoustic guitar (direct in)
Mains:
One K8.2 loudspeaker [preset Acoustic Guitar / Vox; no sub]
Monitor (optional):
One K8.2 loudspeaker [preset Stage Monitor 1]
Preset: ACOUSTIC GUITAR / VOX
K8.2
In A: LINE
Preset: STAGE MONITOR 1
K8.2
vocal mic
A IN—MIC
acoustic guitar
B IN—INST
MIX OUT
A IN—LINE
Optional

QSC K8.2 Specifications

General

Amplifier class	D
Recommended amplifier power (max)	1800 W
Recommended amplifier power (min)	225 W
Amplifier/receiver input interface type	3.5 mm jack, XLR
Certification	CE, WEEE, UL, China RoHS, RoHS II, FCC B
Product color	Black
LED indicators	Yes
RMS rated power	- W
Housing material	Acrylonitrile butadiene styrene (ABS)
Recommended usage	Universal
Audio output channels	1.0 channels
Multi-Room Streaming (MRS) support	-
Speaker type	2-way
Number of drivers	2
Speaker placement	Floor
AirPlay	No
Display	1.75\
Transducer material	Titan
Frequency range	55 - 20000 Hz
Connectivity technology	Wired
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package weight	14400 g
Speaker interface type	XLR

Weight and Dimensions

Depth	269 mm
Width	280 mm
Height	449 mm
Weight	12200 g
