QSC K8.2 Application Guide

K.2 APPLICATION GUIDE— Solo/Duo Musicians 7
DUO: GUITAR, BASS, & VOCALS
This guitar/bass duo both sing. Their system consists of a small digital mixer to combine the two vocal mics plus the guitar and
bass fed through DI boxes. The mixer’s main outputs feed the two K10.2 loudspeakers serving as mains.
Two vocal mics
One acoustic guitar (direct in)
One electric bass (direct in)
Digital mixer
Mains:
Two K10.2 loudspeakers [preset Live; no sub]
TECH REQUIREMENTS:
K10.2
In A: LINE
Preset: LIVE
No sub
K10.2
TouchMix -8
™
L R
L
In A: LINE
Preset: LIVE
No sub
R
Aux Out
Main Out

QSC K8.2 Specifications

General

Amplifier class	D
Recommended amplifier power (max)	1800 W
Recommended amplifier power (min)	225 W
Amplifier/receiver input interface type	3.5 mm jack, XLR
Certification	CE, WEEE, UL, China RoHS, RoHS II, FCC B
Product color	Black
LED indicators	Yes
RMS rated power	- W
Housing material	Acrylonitrile butadiene styrene (ABS)
Recommended usage	Universal
Audio output channels	1.0 channels
Multi-Room Streaming (MRS) support	-
Speaker type	2-way
Number of drivers	2
Speaker placement	Floor
AirPlay	No
Display	1.75\
Transducer material	Titan
Frequency range	55 - 20000 Hz
Connectivity technology	Wired
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package weight	14400 g
Speaker interface type	XLR

Weight and Dimensions

Depth	269 mm
Width	280 mm
Height	449 mm
Weight	12200 g
