TD-001536-01-B
KS118
K8.2/
CP8
K10.2/
CP12
K12.2 KW122 KW152 KW153
KLA12
× 1
KLA12
× 2
SP-16X Ext. Pole
4 4 4 4 4 4 4 4
SP-26 Pole
4 4 4 4 4 4 4 4
SP-36 Pole
4 4 4 4 4 6 4 6
KS118 × 2
K8.2/
CP8
K10.2/
CP12
K12.2 KW122 KW152 KW153
KLA12
× 1
KLA12
× 2
SP-16X Ext. Pole
4 4 4 4 4 4 4 6
SP-26 Pole
4 4 4 4 4 6 4 6
NOTE: Do not use the configurations marked by a red X (6)
unless the subwoofer or subwoofers are properly secured or
restrained (Figure 15) to prevent them leaning more than 10 degrees
in any direction.
WARNING: Do not fly or suspend any KS Series subwoofer. It is not
intended or equipped for flying or suspension. Use only on a flat surface,
such as a floor or stage.
– Figure 15 –
