SPECIFICATIONS SPÉ CIFICATIONS TECHNISCHE DATEN ESPECIFICACIONES
PL218 PL224 PL230 PL236
OUTPUT POWER in watts
FTC:
8 ohms per channel (20 Hz–20 kHz, 0.03% THD) 310 440 575 725
4 ohms per channel (20 Hz–20 kHz, 0.05% THD) 525 725 900 1100
EIA: 1 kHz @ 1% THD
8 ohms per channel 340 475 625 800
4 ohms per channel 600 825 1050 1300
2 ohms per channel 900 1200 1500 1850
Bridged Mono:
16 ohms, 20 Hz–20 kHz, 0.1% THD 650 900 1200 1500
8 ohms, 20 Hz–20 kHz, 0.1% THD 1100 1500 1800 2400
4 ohms, 1 kHz, 1% THD 1800 2400 3000 3600
DYNAMIC HEADROOM N/A N/A N/A N/A
DISTORTION (all models)
SMPTE-IM Less than 0.01%
Typical, 10 dB below rated power, 20 Hz–20 kHz <0.015
Typical, full rated power, 5 kHz
FREQUENCY RESPONSE (all models) 20 Hz to 20 kHz, ±0.2 dB
(at 10 dB below rated output power) -3 dB points: 8 Hz and 100 kHz
DAMPING FACTOR (all models) Greater than 500
NOISE (unweighted, 20-20k Hz.) -107 dB -108 dB -107 dB -107 dB
VOLTAGE GAIN 32 dB 34 dB 35 dB 36 dB
INPUT SENSITIVITY, V
rms
for rated power into 8 ohms 1.23 V 1.16 V 1.17 V 1.23 V
for rated power into 4 ohms 1.16 V 1.10 V 1.07 V 1.07 V
INPUT CLIPPING, Vrms (all models) 10 V
INPUT IMPEDANCE (all models) 6 kW unbalanced
12 kW balanced
CONTROLS (all models) Front: AC switch, Ch. 1 and Ch. 2 gain knobs
Rear: DIP Switch for Ch.1and Ch.2: clip limiter on/off, LF fliter on/off, LF filter freq. select 30 or 50 Hz., inputs parallel or stereo, bridge mode
INDICATORS (all models) POWER ON: Green LED CLIP/Protect: Red LED, 1 per channel
STANDBY: POWER LED 1/2 brightness Level -10 dB: Amber LED, 1 per channel
BRIDGED: Yellow LED Level -20 dB: Green LED, 1 per channel
PARALLEL: Orange LED SIGNAL -35dB : Green LED, 1 per channel
CONNECTORS (all models) Input: XLR (pin 1, earth; pin 2, +; pin 3, -) and 1/4" (6.3 mm) TRS (tip, +; ring, -; sleeve, earth) and 3-pin detachable terminal block (pin out labeled)
Output: “Touch-Proof” binding posts and Neutrik® Speakon connectors
