28
EN EN
TD-000368-00-A
Heat Loss Charts
BTU/hr kcal/hr
Idle
PLD 4.3 225 57
PLD 4.5 286 72
Load per Channel 8Ω 4Ω 2Ω
BTU/hr kcal/hr BTU/hr kcal/hr BTU/hr kcal/hr
1/8th Power
PLD 4.3 684 172 794 200 1040 262
PLD 4.5 811 204 1144 288 1124 283
1/3rd Power
PLD 4.3 983 248 1261 318 1869 470.988
PLD 4.5 881 222 170 8 430 1737 438
Full Power
PLD 4.3 2498 629 2925 737 4198 1058
PLD 4.5 3116 785 5318 1340 4208 1060
Idle
Thermal loss at idle or with very low signal level.
1/8 Power
Thermal loss at 1/8 of full power is measured with pink noise. It approximates operating with music or voice with light clipping and represents the
amplifier's typical "clean" maximum level, without audible clipping. Use these figures for typical maximum level operation.
1/3 Power
Thermal loss at 1/3 of full power is measured with pink noise. It approximates operating with music or voice with very heavy clipping and a very
compressed dynamic range.
Full Power
Thermal loss at full power is measured with a 1 kHz sine wave. However, it does not represent any real-world operating condition.
NOTE:
Specifications are subject to change without notice.
