QSC PLX Series

PLX 1602 PCB ASSEMBLY (230V) Cont’d
PLX 1602 CHASSIS ASSEMBLY (230V)
Part Number Description Reference
REF:D87,88
WC-000001-10 JUMPER INS .6” 22AWG SOLID W R224
WC-000103-00 CABLE ASSY, 20 PIN 9”L J3-4,J5-6
WC-0001 15-00 AC SWITCH WIRE, BLK, LONG REF:ES2,
TO SWITCH
WC-0001 15-01 AC SWITCH WIRE, RED, SHORT REF:ESl,
WC-0001 15-01 AC SWITCH WIRE, RED, SHORT TO SWITCH
WC-0001 17-00 SPEAKER WIRE, BIACK El2A-12C
REF:
WC-0001 17-01 SPEAKER WIRE, WHITE E9A-9C
REF:
WC-0001 17-02 SPEAKER WIRE, GREY EIIA-IIC
REF:
WC-0001 17-03 SPEAKER WIRE, BLACK EIOA-IOC
REF:
WC-0001 18-00 WIRE ASSY, BLK, LONG EHI-EH2
REF:
XF-000005-00 BEAD FERRITE W/2OAWG LEAD L9,lO
XF-000023-00 CHOKE COMMON MODE 2.2MH L3,4
XF-000061-00 INDUCTOR TORIOD 1.9UH 13GA L6
XF-000063-00 XFMR, PWR PLXl602 T2
XF-000064-00
XFMR AMP HOUSEKEPPING PLC Tl
XF-200014-CR INDUCTOR 2UH 14AWG VERT M Ll,2
PLX 1602 CHASSIS ASSEMBLY (12OV)
Part Number Description Reference
CH-000097-00 CHASSIS, PLX
CH-000100-00 HANDLE-EAR CASTING PLX
CH-000112-00 SHIELD, AC, PLX
LB-000052-00 LABEL, cUL APPROVAL
LB-000053-00 LBL, FRENCH, FUSE REPLACEMENT
LB-000077-00 LABEL,WARNlNG,HlGH ENERGY
LB-000214-00 LABEL, FACEPLATE PLX 1602
LB-000215-00 LABEL, INPUT/OUTPUT, PLX
LB-160226-05
lABEL, FUSE, UL CAUT. 25A 125V
NW-380801-IL 3/8” INTERNAL TOOTH LOCKWASHER
PL-000003-CP AC CORD PROTECTOR
PL-000040-PL POT COVERS
PL-000044-PL BUSHING, STRAIN RELIEF
PL-000054-00 KNOB FAB.
PL-000066-00 CLIP XMAS-TREE SLG HEAD FASTEX
PL-000095-00 FAN INTERFACE PLX
PL-000096-00 lNSULATOR,FAN DUCT, PLX
SC-025000-PP SCREW M2.5 X 6MM TYPE 1 PH BLK
SC-060060-PS SCREW 6-32 X ,375 SEMS EXTL ZC
SC-082051-PL SCREW,TAP,PAN PH#8X5/16” “B”BK
SW-000016-S
SPST SNAP IN POWER SWITCH
WC-0001 14-00 AC CORD ASSY PLX
WP-000057-00 FAN ASSY, 3.15” 24VDC W/5.5L”
WP-000516-00 PCB ASSY, PLX 1602 (IZOV)
Part Number Description Reference
CH-000097-00 CHASSIS, PLX
CH-000100-00 HANDLE-EAR CASTING PLX
CH-000112-00 SHIELD, AC, PLX
LB-000053-00 LBL, FRENCH, FUSE REPLACEMENT
LB-000077-00 LABEL,WARNlNG,HlGH ENERGY
LB-000099-01 LABEL, CE LISTING
LB-000214-00 LABEL, FACEPLATE PLX 1602
LB-00021 5-00
LABEL, INPUT/OUTPUT, PLX
LB-160226-01
LABEL, FUSE, UL CAUT. 15A 250V
NW-380801-IL 3/8” INTERNAL TOOTH LOCKWASHER
PL-000003-CP AC CORD PROTECTOR
PL-000024-00 STRAIN RELlEF,LlQ.TlGHT,HEYCO
PL-000040-PL POT COVERS
PL-000054-00 KNOB FAB.
PL-000055-00 EXPORT BINDING POST PLUG(RED)
PL-000056-00 EXPORT BINDING POST PLUG(BLK)
PL-000066-00
CLIP XMAS-TREE SLG HEAD FASTEX
PL-000095-00 FAN INTERFACE PLX
PL-000096-00 lNSULATOR,FAN DUCT, PLX
SC-025000-PP SCREW M2.5 X 6MM TYPE 1 PH BLK
SC-060060-PS SCREW 6-32 X ,375 SEMS EXTL ZC
SC-082051-PL SCREW,TAP,PAN PH#8X5/16” “B”BK
SW-000016-S
SPST SNAP IN POWER SWITCH
WC-0001 34-00 AC CORD ASSY, 23OV, PLX
WP-000057-00 FAN ASSY, 3.15” 24VDC W/5,5L”
WP-000516-02 PCB ASSY, PLX 1602 (230V)
34
