QSC Q-SYS CORE NANO User Manual

13
TD-001615-00-A
Specification Value
Sample Rate 48 kHz
USB Audio Device Hosting Support for standard USB headset, speakerphone on USB type A connection
(one device at a time)
Input
Sample Rate 48kHz or 16kHz, monaural
Bit Resolution 8-bit, 16-bit, 24-bit or 32-bit floating point (IEEE 754)
Format Little-endian, signed or unsigned
Output
Sample Rate 48kHz or 16kHz, monaural
Bit Resolution 16-bit
Control
RS232 2 ports
GPIO (Core 8 FLEX only) 8x8
Panel Indicators and Controls
Front Panel LEDs POWER (blue LED), ID (green LED)
Front Panel Control ID button (momentary)
Rear Panel Indicators LAN A, LAN B: Link, Speed, Activity (multi-color LEDs)
Physical
Product Dimensions (L x W x H) 11.28 x 8.66 x 1.72 in (286.6 x 220.0 x 43.6 mm)
Product Weight 4.0 lbs. (1.8kg) Core 8 FLEX, 3.6 lbs. (1.6kg) Core NANO
Shipping Weight (Gross Weight) 6.4 lbs. (2.9kg) Core 8 FLEX, 4.9 lbs. (2.2kg) Core NANO
Environmental
Power Consumption 40W typical, 60W maximum
Cooling Active, single variable speed fan
Operating Temperature Range 0°C to +50°C
Storage Temperature Range -20°C to +70°C
Relative Humidity 5% to 85% RH, non-condensing
BTU, Heat Load 110 BTU/Hr.
Compliance
FCC Part 15B, ICES-003:2016, UL, CAN/CSA 22.2, IEC62368-1, IEC60065, ROHS2, WEEE, CE, EN55032, EN55035, EN61000-3-2, EN61000-3-3, CB report,
RCM: AS/NZ S32, NOM, GB8898, GB13837, GB17625.1, SJ/T 1164 (ROHS), SANS 941, LOA, EAC: TR-CU-004, TR-TC-020, BIS, KN32, KN35, KC60065, SASO
