12
TD-001615-00-A
Specifications
Specification Value
FLEX Audio Inputs (Core 8 FLEX only)
Input Frequency Response
20 Hz to 20 kHz @+24 dBU +0.05 dB/-0.5 dB
Input THD+N @ 1 kHz
@ +24 dBu sensitivity and +24 dBu input < 0.004 %
@ -40 dBu sensitivity and -40.5 dBu input <0.009%
Input to Input Crosstalk @1 kHz
@+24 dBu sensitivity
@+10 dBu sensitivity
<-110 dB Typical, -95 dB Max
<-120 dB Typical, -110 dB Max
Input Dynamic Range
@+24 dBu sensitivity > 108 dB
@-10 dBu sensitivity > 105 dB
EIN (no weighting, 20 Hz to 20 kHz) <-122 dB
Input Impedance (balanced) 10.5 k Ω, nominal
Input Sensitivity Range (1 dB Steps) -40 dBu to +24 dBu
Maximum Input Level for unbalanced signals +23 dBu
Phantom Power IEC 61938 P48 compliant, +48VDC, 10mA per channel
A/D Converters 24-bit, 48 kHz
FLEX Audio Outputs (Core 8 FLEX only)
Output Frequency Range
20 Hz to 20 kHz @ all settings +0.5/-0.3 dB
Output THD, +20 dBu @ 1 kHz 0.007% typical
Output Crosstalk @ 1 kHz < -102 dB typical, -90 dB max
Output Dynamic Range > 108 dB
Output Impedance (balanced) 100 Ω, nominal
Output Level Range (1 dB steps) -40 dBu min to +20 dBu max
D/A Converters 24-bit, 48 kHz
Capacities
Q-LAN or AES67 Channels 64x64
Core-to-Core Streaming Channels 64x64
Dante Channels Default = 8x8 (up to 32x32 upgrade available)
WAN/Media Streaming Channels 12x12
AEC Processors 8
Softphone Intances Up to 2
Network Peripherals (max quantity) 32 (includes native Q-SYS cameras, I/O, NV, TSCs, paging stations, Extensions
and plugins with their “Is Managed” property set to “Yes”. It does not include
Streaming I/O, Loudspeakers, Scripts or plugins with their “Is Managed”
property set to “No”.)
MTP (Multi-Track Player) Default = 16 (up to 32x32 upgrade available Spring 2021)
Media Drive Storage Default = 14GB (128GB, 256GB or 512GB upgrades available Spring 2021)
USB Inputs and Outputs
USB B or USB C (Audio)
Bit Depth 24-bit
Channel Quantity 8x8
