136 137
Parameter QT504 QT528 QT526
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 4
Composite 1.0V
p-p/75Ω,
BNC x 8
Composite
1.0V p-p/75Ω,
BNC x 16
Video Out COMPOSITE 1.0V p-p/75Ω, BNC x 2, VGA x 1
VGA Resolution 1280x1024, 1024x768, 800x600
Record
Resolution
NTSC: 352x240, 704x480
PAL: 352x288, 704x576
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC: D1 30FPS CIF 30FPS
PAL: D1 25FPS CIF 25FPS
AUDIO Audio Input -8dB~ 22k, RCA X4
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input NO or NC 4CH NO or NC 8CH NO or NC
16CH
Alarm Output 1CH
FUNCTION Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Simultaneously Record, View Live or Recorded Video,
Playback, Back-up files, Monitor Remotely
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
RS485,
USB 2.0 x 2 (One for Backup, One for USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 1 (up to
2TB each)
SATA x 2 (up to 2TB each)
OTHER INFO Voltage 12V3A 12V4A 12V5A
Optimal
Temperature
32°F to 122°F 10°C to 50°C
10% to 90% Humidity
Power Use
w/o Hard Drive
10W 18W 30W
Parameter QT4532 QT4516 QT4760
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 32
Composite 1.0V p-p/75Ω,
BNC x 16
Video Out COMPOSITE 1.0V p-p/75Ω, BNC
x 1, VGA x 1, HDMI x 1
COMPOSITE
1.0V p-p/75Ω,
BNC x 2, VGA x
1, HDMI x 1
VGA Resolution 1920x1080 1280x1024,
1024x768, 800x600
1280x1024,
1024x768,
800x600, HDMI
Record
Resolution
NTSC: 352x240, 704x480
PAL: 352x288, 704x576
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC: D1 7.5FPS CIF 30FPS
4CH D1 30FPS if others CIF
PAL: D1 6.25FPS
CIF 25FPS
NTSC: 30FPS
PAL: 25FPS
AUDIO Audio Input -8dB~ 22k,
RCA X16
-8dB~ 22k, RCA X4
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input NO or NC 16CH
Alarm Output 4CH 1CH
STORAGE Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Multiplex
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
eSATA x2
RS485,
USB 2.0 x 2
(One for
Backup, One for
USB Mouse)
RS485,
USB 2.0 x 2 (One for Backup, One
for USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 8 (up to
2TB each)
SATA x 1 (up to
2TB each)
SATA x 2 (up to
3TB each)
OTHER INFO Voltage 110/220 12V3A
Optimal
Temperature
50°F to 104°F 10°C to 40°C
10% to 90% Humidity
Power Use
w/o Hard Drive
42W 20W 18W
