6
SPECIFICATIONS
Model
Artera Mono
Loudspeaker Phasing
Make sure that both channels are connected in phase. The positive (red) output terminal of each channel should be
connected to the positive (red) terminal of the speaker. Special care should be taken when the bi-wiring phase becomes
critical.
If there is a doubt about the way the loudspeakers are connected, check their phasing by playing a mono source - the sound
should appear from a point midway between the two loudspeakers. If this position is unfocused, reverse the connections
to one of the midrange. Correctly connected loudspeakers give a defined centre sound source with fuller-bodied midrange
and bass registers.
(Measurement made with 230V supply, one channel driven and applied to either channel)
Rated Output Power 300W @8ohms (THD=1%, 1kHz)
400W @4ohms (THD=1%, 1kHz)
Total Harmonic Distortion
<0.006% (100W, 1kHz, bandwidth 20Hz-20kHz)
<0.03% (100W, 10kHz, bandwidth 20Hz-90kHz)
Frequency Response
﹢/﹣0.3dB (20Hz-20kHz, ref. 1kHz)
Input Sensitivity
0.98Vrms (Unbalanced), 2.1Vrms (Balanced)
Input Impedance
10K ohms (Balanced/Unbalanced)
Signal to Noise Ration (S/N) 112dB (A-weighted, ref. 300W)
Power Requirement
220V-240V~50/60Hz
100V-115V~50/60Hz
Maximum Power Consumption 750W
Standby Power Consumption <0.5W
Dimensions (mm) (W x H x D) 320 x 158 x 338
Carton Size (mm) (W x H x D) 465 x 260 x 465
Weight
13kg (Net)
17kg (Gross)
