Quadra-Fire • EXCURSION-I, EXCURSION-II, EXCURSION-III Owner’s Manual • 2538-981 Rev. B • 2/19
Service Parts
R
Beginning Manufacturing Date: March 2019
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer
or distributor. Hearth and Home Technologies does not sell directly to consumers.
Provide model number and serial number when requesting service parts from your dealer
or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Log Assembly (Hearth Refractory not Included)
LOGS-2537
Y
1 Log 1
SRV2537-711
2 Log 2
SRV2537-712
3 Log 3
SRV2537-713
4 Log 4
SRV2538-714
5 Log 5
SRV2537-716
6 Log 6
SRV2537-717
7 Log 7
SRV2537-715
8 Slide Plate Assembly 2532-014
Tool, Slide Plate (Multi-purpose) 2532-140
Gasket 2532-113
9 Glass Clip Assembly, Top Qty 2 req 2155-046
10 Baf e, Firebox 2531-138
11 Glass Clip Assembly, Bottom Qty 2 req 2532-009
12 Air Scoop 2532-135
13 Pilot Shield 2532-153
14 Burner Assembly 2537-007 Y
15 Base Pan 2537-130
16 Grate 2537-014
17 Refractory Assembly SRV2537-076
Hearth Refratory SRV2537-703
18 Seal, Glass Frame 2531-122
19
Glass Door Assembly
GLA-2531 Y
20
Power Cord
2201-024 Y
Fan
GFK-160A Y
Additional service part numbers appear on following page.
EXCURSION-I

Quadra-Fire EXCURSION-I Specifications

General

Brand	Quadra-Fire
Model	EXCURSION-I
Category	Indoor Fireplace
Language	English
