Quadra-Fire • EXCURSION-I, EXCURSION-II, EXCURSION-III Owner’s Manual • 2538-981 Rev. B • 2/19
Service Parts
R
Beginning Manufacturing Date: March 2019
Ending Manufacturing Date: Active
1
2
3
4
5
6
7
EXCURSION-II
30” Gas Insert - DV
Log Set Assembly
Part number list on following page.
02/19
8
9
11
17
18
19
20
23
24
10
25
22
16
15
14
13
12
21
Service Parts
R
Beginning Manufacturing Date: March 2019
Ending Manufacturing Date: Active
EXCURSION-II
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer
or distributor. Hearth and Home Technologies does not sell directly to consumers.
Provide model number and serial number when requesting service parts from your dealer
or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Log Assembly (Hearth Refractory not Included)
LOGS-2538
Y
1 Log 1
SRV2538-711
2 Log 2
SRV2538-712
3 Log 3
SRV2538-713
4 Log 4
SRV2538-714
5 Log 5
SRV2538-716
6 Log 6
SRV2538-717
7 Log 7
SRV2538-715
8 Slide Plate Assembly 2532-014
Tool, Slide Plate (Multi-purpose) 2532-140
Gasket 2532-113
9 Glass Clip Assembly, Top Qty 2 req 2155-046
10 Baf e, Firebox 2532-138
11 Glass Clip Assembly, Bottom Qty 2 req 2532-009
12 Light Glass, Hold Down Qty 2 req 2532-149
13 Accent Glass Qty 2 req 2532-151
14 Light Glass Gasket Qty 4 req 2532-150
15 Halogen Re ector Lamp, 50W Qty 2 req 2201-150
Y
16 Light Tub Assembly Qty 2 req 2532-006
Light Wire Assembly 2532-017
Y
17 Air Scoop 2532-135
18 Pilot Shield 2532-153
19 Burner Assembly 2538-007 Y
20 Base Pan 2538-130
21 Grate 2538-014
22 Refractory Assembly SRV2538-076
Hearth, Refractory SRV2538-703
23 Seal, Glass Frame 2532-122
24
Glass Door Assembly
GLA-2532 Y
25
Power Cord
2201-024 Y
Fan
GFK-160A Y
Additional service part numbers appear on following page.
