Quadra-Fire QFP 30 - Clearances

Page 7
03/21/01 #250-6120 03/21/01 #250-6120
QFP 30 Direct Vent Gas Fireplace
CLEARANCES TO COMBUSTIBLES
CLEARANCES TO COMBUSTIBLES
SEE ALSO:
Floor to Mantel Height Dimensions on Page 14 AND
Facing Dimension Requirements on Page 15
MAINTAIN 1/2” CLEARANCE TO COMBUSTIBLES ON
SIDES AND REAR OF FIREPLACE.
23-1/2"
12" Max.
18-3/4"
Trim 2-1/4" Max.
GLASS
ADJACENT WALL
11"
FASCIA
5-1/2"
14"
9-1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
