Quadra-Fire QV36DB-A - Service Parts Lists

Quadra-Fire • QV36DB-A • 2018-900 Rev. F • 12/07 5
Service Parts List
QV36DB-A
Pilot Orifice LP
446-517 Y
Additional service part numbers appear on following page.
ITEM DESCRIPTION SERIAL # PART NUMBER
Log Set Assembly LOGS-2018 Y
1Log 1 SRV2018-701 N
2Log 2 SRV385-736 N
3Log 3 SRV278-704 N
4Log 4 SRV2018-704 N
5Log 5 SRV780-707 N
6 Non Combustible board 385-401 N
7 Refractory Kit (Sold as set only)
BRICK-292 N
8 Log Grate 2018-001 N
9 Andirons, Cast 80784 N
10 Base Refractory NG, LP 2018-100 N
11 Surround 2026-108 N
12 Glass Door Assembly GLA-6TRXI Y
13 Burner
2018-005 Y
14 Junction Box 4021-013 Y
Mesh Mesh -6000 Y
Glass Latch Assembly 386-122A Y
Exhaust Restrictor 2027-102 N
Pilot Tube
SRV485-301 Y
Thermocouple
446-511 Y
Thermopile
060-512 Y
Lava Rock Bag 060-721 N
Mineral Wool 050-721 N
Gasket Assembly
Includes: Vent, Seal Cap, Burner Neck, Shutter
Bracket, and Valve Plate Gaskets
Touch Up Paint TUP-GBK-12 N
Conversion Kit NG
NGK-2018 Y
Conversion Kit LP
LPK-2018 Y
Regulator NG
060-518 Y
Regulator LP
060-519 Y
Pilot Orifice NG
446-505 Y
IMPORTANT: THIS IS DATED INFORMATION. When Requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
N385-402A
