In the Box
Parts
A
1. Remove all parts of the rear roller cylinder mower from the box and carefully remove all
packaging. Take care not to lose any instructions which may be attached to the parts. These
provide important information which will be required while assembling the rear roller cylinder
mower.
2. Keep all packaging until the rear roller cylinder mower is fully assembled and has been
operated successfully.
Please keep original packaging for warranty purposes.
Locate the lower handle to the slot on deck, and tighten the xing screws on both side.
NOTE! Make sure that the cable hooks are at the back side of the machine.
Preparing to assemble the Rear Roller Cylinder Mower
Assembly
Step 1 - Assemble the lower handles
A
Main unit with upper
handle
B
Lower handle
C
Grass bag
D
CAM lever 4pcs
E
Cable clip, 2pcs
F
Cable retainer
G
Screw, 2pcs
H
Middle handle
B
H
D EC F G
If there are any parts missing, please call the customer helpline on 01904 727500
