Qualcast XSS46D - In the Box; Parts Identification; Tools Required

4
Customer Helpline 01904 727500
www.gardenservicecentre.co.uk
In the Box
Parts
Tools
You will also need:
- SAE30 or 4-stroke oil - Unleaded fuel - Funnel
If there are any parts missing, please call the customer helpline on 01904 727500
A
Main mower deck
(with upper handle
attached)
B
Lower handle
C
Quick release 2pcs
D
Lower handle xing
knob with nut M8
2pcs
E
Rope guide 1pc
(attached to the
lower handle)
F
Grass collecting
bag 1pc
G
Cable clip 1pc
1
Spanner & philips
screwdriver 1pc
D
C
1
G
F
B
A
E
