11
PARTS SCHEMATIC LIST
No. DESCRIPTION Qty
1 Lever Mount Nut 1
2 Nut Cap M10 3
3 Lever 1
4 Lever Knob 1
5 Guard Plate 1
6 Nut 2
7 Copper Gasket 4
8 Screw M8 1
9 O-Ring 5.5x2 1
10 Snap Washer – Shaft 1
11 Valve Retract Spring 1
12 O-Ring , 6.7x1.8 1
13 Valve Core Rod 1
14 Sliding Pressure Sensor Sleeve 1
15 Sliding Pressure Sensor Sleeve Spring 1
16 Aluminum Cover (Rear) 1
17 O-Ring 55x3.1 1
18 Piston 1
19 Piston Ring 1
20 O-Ring 32x3.5 1
21 Spring 1
22 Stud 4
23 Hydraulic Cylinder 1
24 Aluminum Cover (Front) 1
25 Piston Rod Seal 1
26 O-Ring 7x1.9 1
27 Wing Bolt 1
28 Flat Washer Groupware M14 1
29 Dipstick 1
30 Piston Rod 1
31 Lift Handle 1
32 Screw M6x16 2
33 Frame Tube 1
34 Lead Plank 2
35 Spring Washer M6 4
36 Screw M6x10 4
37 Nut M14 2
38 Flat Washer 2
39 Nut 2
40 Spring Gasket 2
41 Nut Plug 1
42 Flat Washer Groupware M18 1
43 Valve Sleeve 1
44 O-Ring 12.5x1.8 5
45 Adjusting Screw 1
46 Steel Ball 1
47 Pressure Limited Valve Spring 1
48 Adjusting Screw 1
49 Log Pusher Connection Weldment 1
50 Plastic Insert 1 1
51 Plastic Insert 2 1
52 Gasket 5
53 Log Pusher 1
54 Nut M10 4
55 Screw M10x25 4
56 Wheel Cover 2
57 Block Turn 2
58 Wheel 2
59 Bolt 4
60 Washer 8
61 Shelf 1
62 Bolt 6
63 Spring Washer 9
64 Washer 9
65 Gear Pump Cover 1
66 O-Ring 10.6x2.65 2
67 Gear Housing Plate 1
68 C-Clip 2
69 Gear Shaft 1
70 Steel Ball 1
71 Gear 2
72 Pin 1
73 Washer 6
74 Bolt 3
75 Motor Cover 1
76 Seal 1
77 Nut 1
78 Screw 1
79 Motor 1
80 Fan 1
81 Block Turn 1
82 Shroud 1
83 Spring Washer 5
84 Screw 2
85 Bolt 7
86 Leg 1
87 Leg Cover 2
88 Cable & Plug 1
89 Nut 4
90 Cord Stop 1
91 Bolt 1
92 Circuit Breaker 1
93 Screw 8
94 Switch Box Cover 1
95 Airproof Underlay 1
96 Connection Terminal 1
97 Capacitor 1
98 Switch 1
99 Switch Box 1
100 Waterproof Underlay 1
101 Left Motor Support Shoe 1
102 Right Motor Support Shoe 1
103 Pin 2
104 Sping 2
105 Sliding Sleeve 4
To Next Page
