4
APPLICATION CONDITIONS / SPECIFICATIONS / ELECTRICAL REQUIREMENTS
PROTECT THE ENvIRONMENT
Take used oil to an authorized collection point or follow the stipulations in the country
where the log splitter is used. Do not discharge into drains, soil or water.
MAINTAIN YOUR LOG SPLITTER WITH CARE
Keep the log splitter clean for best and safest performance.
MAKE THE WORKSHOP CHILDPROOF
Lock the shop. Disconnect master switches. Store the log splitter away from children
and others not qualified to use it.
APPLICATION CONDTIONS
This log splitter is a home use model. It is designed for operating under ambient temperatures between 5˚ C - 40˚ C (41˚ F and 104˚ F) and
for installation at altitudes no more than 1,000 metres (3,281 feet) above M.S.L. The surrounding humidity should be less than 50% at 40˚ C
(104˚ F). It can be stored or transported under ambient temperatures between 10.5˚ C - 55˚ C (13˚ F and 131˚ F).
SPECIFICATIONS
* The diameter of the log is indicative – a small log can be difficult to split when it has knobs or a particularly tough fiber. On the other hand, it
may not be difficult to split logs with regular fibers even if its diameter exceeds the max figure indicated above.
ELECTRICAL REQUIREMENTS
Connect the main leads to a standard 110 volt electrical supply which has protection devices of under-voltage, over-voltage, over-current as
well as a residual current device (RCD) with a maximum residual current rated at 0.03A.
SYMBOL AFFIXED TO MACHINE
