- The Q10 grinder has two images as main screens. These two images alternate every 10 seconds. They are
identified with the following file names: Q10_1.bmp and Q10_2.bmp.
- Q10_1.bmp: This image provides no additional information.
- Q10_2.bmp: At the bottom left of the image there is a bar that indicates the operating mode which has been
selected for the grinder; pre-grinding, instant or manual grinding. At the bottom right users can view the
number of partial coffees served until that moment and the icon of the current serving can be seen in the
centre.
- 1. Copy the two images or only one, according to the user's request, to a USB memory stick. Make sure that
the respective names of the files coincide with those described above, and that they are in the following
format:
Standard BMP file extension (bitmap format)
Dimensions of the image 320x240 pixels
Maximum size of 262 kB.
- To change the format of the image we wish to use, follow these instructions:
- Open the image using Microsoft Office.
- At the top menu, click on “Image” and select the option “Change Size”
- In the boxes on the right side, go to “Customised Width x Size” and choose 320x240 pixels.
- Click on “Accept”
- In the menu option “File” choose the option “Export”, go to the right side box “Export in this file
format”, of the two fold-down options, select “Windows Bitmap” (*. bmp) and rename the file
using Q10_1.bmp or Q10_2.bmp
- Lastly, click on “Accept”
- 2. Copy the Image file into the root of the USB memory stick.
- 3. Insert the USB memory stick and follow the instructions shown below.
