Mounting your PC to a monitor
1. Firstly, mount your VESA kit on the backside of the monitor with four screws in
the package.
2. Secondly, place the QDSP-2070 on the VESA mounting kit and then tightening
the screws from the holes on both sides of the VESA bracket - make sure the
computer is fitting well on the bracket.
Figure 11 VESA mounting
NOTE
To fasten the metal shelf, your monitor must comply with VESA75 or
VESA100 standard.
Remarks: VESA mounting kit could be used as wall mounting kit as well.
