FORM QTC3-EG6 (1118)
QUANTECH
15
Unit Components
FIGURE 1 - QTC3 UNIT COMPONENTS
FAN DECK
MICROCHANNNEL
COILS
COIL
HEADERS
CONTROL AND
POWER
PANELS
COMPRESSORS
BRAZED PLATE
EVAPORATOR
FORMED STEEL BASE
RAILS
HYDRO-KIT
PUMPS AND
MOTORS
(OPTIONAL)
LD18426
