Quantech QTC3150THE Manual

QUANTECH
FORM QTC3-EG6 (1118)
44
QTC3 VOLT HZ MCA
MIN N/F
DISC
SW
MIN DUAL
ELEM FUSE
& MIN CB
MAX DUAL
ELEM FUSE
MAX CB
SYSTEM # 1
COMPR 1 COMPR 2 COMPR 3 STD FLOW FANS
RLA LRA RLA LRA RLA LRA QTY FLA LRA
55T
208 60 301 400 300 300 57.7 284 57.7 284 2 7.6 44
230 60 297 400 300 300 57.7 330 57.7 330 2 7.4 37
380 60 162 200 175 175 30.9 192 30.9 192 2 4.5 23.1
460 60 141 200 150 150 26.9 180 26.9 180 2 4 19
575 60 106 150 110 110 21.5 132 21.5 132 2 2.9 15.3
60T
208 60 331 400 350 350 48.5 249 48.5 249 48.5 249 2 7.6 44
230 60 327 400 350 350 48.5 288 48.5 288 48.5 288 2 7.4 37
380 60 183 250 200 200 27.6 159 27.6 159 27.6 159 2 4.5 23.1
460 60 161 200 175 175 24.4 145 24.4 145 24.4 145 2 4 19
575 60 116 150 125 125 17.4 109 17.4 109 17.4 109 2 2.9 15.3
70T
208 60 359 400 350 350 48.5 249 48.5 249 48.5 249 2 7.6 44
230 60 354 400 350 350 48.5 249 48.5 249 48.5 249 2 7.4 37
380 60 204 250 225 225 27.6 159 27.6 159 27.6 159 2 4.5 23.1
460 60 179 200 175 175 24.4 145 24.4 145 24.4 145 2 4 19
575 60 124 150 125 125 17.4 109 17.4 109 17.4 109 2 2.9 15.3
75T
208 60 388 600 400 400 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 384 600 400 400 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 214 250 225 225 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 187 200 200 200 26.9 180 26.9 180 26.9 180 2 4 19
575 60 137 150 150 150 21.5 132 21.5 132 21.5 132 2 2.9 15.3
79T
208 60 388 400 400 400 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 384 400 400 400 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 214 250 225 225 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 187 200 200 200 26.9 180 26.9 180 26.9 180 2 4 19
575 60 137 150 150 150 21.5 132 21.5 132 21.5 132 2 2.9 15.3
85T
208 60 416 600 450 450 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 412 600 450 450 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 224 250 250 250 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 195 200 200 200 26.9 180 26.9 180 26.9 180 2 4 19
575 60 149 150 150 150 21.5 132 21.5 132 21.5 132 2 2.9 15.3
90T
208 60 431 600 450 450 57.7 284 57.7 284 57.7 284 3 7.6 44
230 60 427 600 450 450 57.7 330 57.7 330 57.7 330 3 7.4 37
380 60 233 250 250 250 30.9 192 30.9 192 30.9 192 3 4.5 23.1
460 60 203 250 225 225 26.9 180 26.9 180 26.9 180 3 4 19
575 60 155 200 150 150 21.5 132 21.5 132 21.5 132 3 2.9 15.3
95T
208 60 475 600 500 500 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 471 600 500 500 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 273 400 300 300 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 231 250 250 250 26.9 180 26.9 180 26.9 180 2 4 19
575 60 178 200 200 200 21.5 132 21.5 132 21.5 132 2 2.9 15.3
100T
208 60 483 600 500 500 57.7 284 57.7 284 57.7 284 4 7.6 44
230 60 478 600 500 500 57.7 330 57.7 330 57.7 330 4 7.4 37
380 60 278 400 300 300 30.9 192 30.9 192 30.9 192 4 4.5 23.1
460 60 235 250 250 250 26.9 180 26.9 180 26.9 180 4 4 19
575 60 181 200 200 200 21.5 132 21.5 132 21.5 132 4 2.9 15.3
110T
208 60 522 600 600 600 106.2 523 106.2 523 3 7.6 44
230 60 517 600 600 600 106.2 578 106.2 578 3 7.4 37
380 60 313 400 350 350 64.3 355 64.3 355 3 4.5 23.1
460 60 261 400 300 300 53.1 290 53.1 290 3 4 19
575 60 202 250 225 225 42.5 255 42.5 255 3 2.9 15.3
Electrical Data Without Pumps
NOTES: 1. Reference PIN 59 on the unit panel for pump models.
2. Use this table along with Pump Electrical Data on page 41 to determine electrical data of the unit plus the pump.
3. Does not include the Control Transformer on page 41.
