9. Technical Data
MiniCHILLY
03
MiniCHILLY
05
MiniCHILLY
09
MiniCHILLY
17
IceCHILLY
33
IceCHILLY
77
Refrigerant R 290 290 290 290 290 134a
Cooling capacity (0°Cwater temp.)*
[W] 50Hz 320 312 510 890 3570
Cooling capacity (15°Cwater temp.)*
[W] 50 Hz
460 588 755 1650 7000
Cooling capacity (0°Cwater temp.)*
[W] 60Hz 380 610 1050 1910 4280
Cooling capacity (15°Cwater temp.)*
[W] 60 Hz
650 900 1920 3300 8000
Water tank volume [L] 6,3 27 27 63 67 320
Water connection 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Dimensions Width [mm] 295 370 370 400 530 920
Length [mm] 390 700 700 750 1040 1075
Height [mm] 325 495 495 550 550 785
Weight empty [kg] 21 40 40 51 91 175
Ice bank [kg] 1,2 8 8 12 25 100
Connected load [W] 250 350 490 730 1600 3050
* at 32 °C surrounding temperature
§ Cooling circuits: 1 (type MiniCHILLY), 2 (type IceCHILLY)
§ Evaporator: 1.4301 (stainless steel)
§ Casing: Stainless steel
§ Frequency: 50/60 Hz
§ Voltage: 230 V / 1 Ph
§ Submersible pump with stirrer (see manufacturer)
10. Declaration of conformity
We, WTG-Quantor GmbH, D-54343 Föhren, declare in sole responsibility that the cooling units
MiniCHILLY 03, MiniCHILLY 05, MiniCHILLY 09, MiniCHILLY 17, IceCHILLY 33 and IceCHILLY 77, which
this declaration refers to, comply with the following standards and normative documents.
- EN 60204-1 (VDE 0113)
- DIN 6650
In accordance with the low-voltage directive 2014/35/EU, EG 1935/2004.
This declaration becomes void for any modification ofthe units not agreed with us.
Föhren, 06.06.2016
……………………………………………………
Markus Milz
Managingdirector WTG-Quantor GmbH
