3. Commissioning
1) Remove the lid and fill the water tank with water up to the maximum mark (see water
level device at the MiniCHILLY units). Close the lid.
Never operate the unit when it is open with the lid removed!
2) Connect the water pipes, check for possible leaks
3) Establish the electric network connection (see 1.5 Electrical installation)
4) Start the pump (switch on the pump switch next to the controller)
After start-up of the pump the liquid level may drop as the tubes which are outside of the unit
will start filling with water from the unit container. In this case the liquid level has to be
checked and if necessary water has to be refilled. If you are using Glycol, ensure 30%
concentration in the water of your installation (unit and pipes). Never operate the unit with a
liquid level beneath the lowest water level mark "min“ (at MiniCHILLY units) or the water tank
must be filled with sufficient water all the time in order to protect the unit e.g. against damage
to the pump.
5) Adjust the required temperature on the thermostat (see 5. temperature setting). After
reaching the adjusted set-point temperature the unit is ready for operation.
3.1 Connection
Verify that all connections are sealed. No dirt particles may gain access into the pipes.
3.2 Chart
1 Water level device and tank emptying (only MiniCHILLY) 4 Electric motor of the pump
2 Connection 3/4" 5 Thermostatic controller
3 Cover fastener
