Quantum 610 www.quantumrehab.com 5
II. SAFETY
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to
reduce the risk of leakage or explosive conditions.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand behind or to one side when changing from
drive mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery Configuration:
TT
TT
T = Terminal Post
Connect Red wire to
TT
TT
T with
++
++
+
Connect Black wire to
TT
TT
T with
PRODUCT SAFETY SYMBOLS
The symbols below are used on the power chair to identify warnings, mandatory actions, and prohibited actions. It is very
important for you to read and understand them completely.
