12 DXi6700, DXi6701, and DXi6702 Specifications
DXi6700, DXi6701, and DXi6702 Site Planning Guide
DXi6700, DXi6701, and DXi6702 Specifications
This section lists characteristics and specifications the DXi6700, DXi6701, and DXi6702.
These characteristics and specifications are categorized as follows:
• Physical Characteristics
• Environmental Specifications
Note: For hard drive specifications see the appropriate hard drive product manual.
Physical Characteristics The following tables provide dimensions and other physical characteristics of the
DXi6700, DXi6701, and DXi6702 system components:
• Tab l e 4 - Physical Characteristics
• Tab l e 5 - Storage Capacity
• Tab l e 6 - Cable Drops
• Tab l e 7 - Virtual Device Limits and Hardware Interfaces
• Tab l e 8 - Power Requirements
Table 4 Physical Characteristics
1 8 Width: 52 in. (132.1 cm)
Length: 42 in. (106.7 cm)
Height: 56 in. (91.4 cm)
Approximately 810 lbs. (367.4 kg)
1 9 Width: 52 in. (132.1 cm)
Length: 42 in. (106.7 cm)
Height: 56 in. (116.8 cm)
Approximately 885 lbs. (401.4 kg)
Number of Nodes
Number of
Expansion Modules Pallet Dimensions Total Pallet Weight
Node Expansion Module
Height 5.2 in. (13.2 cm) 3.5 in. (8.9 cm)
Width (side to side) 17.2 in. (43.7 cm) 17.2 in. (43.7 cm)
Depth (front to back) 25.5 in. (64.8 cm) 25.5 in. (64.8 cm)
Weight (stand alone) 72 lbs. (32.7 kg) 52 lbs. (23.6 kg)
Rack Space Required 3U 2U
