Installing the 1U Rackmount Enclosure in a Rack 21
LTO-3, LTO-4, LTO-5, LTO-6, LTO-7 and LTO-8
Figure 25 Installing the Rack
Rails in Front of the Rack
3 Extend the rack rails past the rear vertical mounting bars and attach the back
mounting plate of each outer rail to the rack using four 10-32 screws in the
previously marked holes (see Figure 26
).
Figure 26 Installing the Rack
Rails in the Back of the Rack
The rail installation is complete. Continue with Completing the Installation
