20 Installing the 1U Rackmount Enclosure in a Rack
LTO-3, LTO-4, LTO-5, LTO-6, LTO-7 and LTO-8
Figure 24 Removing the Pins
from the Rack Rails
Note: The ends of the rack rails are marked FRONT and REAR for proper orientation.
2 Attach the front mounting plate of each outer rail to the rack using four 10-32
screws in the previously marked holes in the front vertical mounting bars of the rack
(see Figure 25
).
