Installing a Second Tape Drive or Replacing a Tape Drive 7
LTO-3, LTO-4, LTO-5, LTO-6, LTO-7 and LTO-8
Figure 8 Installing the
Mounting Brackets
4 Install the drive (see Figure 9):
a Position the mounting bracket keyhold slots over the mounting posts.
b Slide the drive toward the back of the enclosure.
c The spring-loaded button will automatically snap into place.
Figure 9 Installing the Tape
Drive
Continue with Connecting the Tape Drive Cables on page 10.
Replacing a Tape Drive:
To replace a tape drive:
Spring-loaded button
Tape drive
