8 Installing a Second Tape Drive or Replacing a Tape Drive
LTO-3, LTO-4, LTO-5, LTO-6, LTO-7 and LTO-8
1 Remove the tape drive (see Figure 10):
a Disconnect all cables from the tape drive.
b Pull the spring-loaded button on the right mounting rail up.
c Slide tape drive forward and lift up out of the 1U rackmount enclosure.
Figure 10 Removing the Tape
Drive
2 Remove the screws securing the mounting brackets to the tape drive (see Figure 11).
Figure 11 Removing the
Mounting Brackets from the
Ta p e D r iv e
Spring-loaded button
Tape drive
