10
NOTE: If your power chair is equipped with an attendant
control, the fender lights will activate using the single
switch when the controller is turned on.
The fender lights operate through a single switch.
To operate the fender lights using the single switch:
1. Press the single switch once to activate the fender lights.
2. Press the single switch again to deactivate the fender
lights.
NOTE: Placing the single switch on the outside of the
power chair, for example, on the side rail, may increase
the overall width of the power chair.
The single switch should be mounted in a location
that is convenient for the power chair user and where
the switch harness will not be caught in drive tires or
running gear, pinched in the seat frame, or damaged
when passing through doorways.
Single Switch Fender Light
Figure 4. Single Switch to Operate Fender Lights
WARNING!
YOUR POWER CHAIR
