PL 124
Techniczne schematy odniesienia
Rys.10 Rys.11
Rys.12
MOTOROVÁ
JEDNOTKA A
MOTOROVÁ
JEDNOTKA B
MOTOROVÁ
JEDNOTKA B
MOTOROVÁ
JEDNOTKA A
Rys.13
175mm
(min)
30mm to 45mm
155mm
(min)
85mm (min)
85mm (min)
2.8mm to 3.5mm
1800mm to 2500mm (max)
