DE 29
Technische Referenzdiagramme
Abb.10 Abb.11
Abb.12
MOTOR EINHEIT A MOTOR EINHEIT B
MOTOR EINHEIT B MOTOR EINHEIT A
Abb.13
175mm
(min)
30mm to 45mm
155mm
(min)
85mm (min)
85mm (min)
2.8mm to 3.5mm
1800mm to 2500mm (max)
