Quattro Titanium - Technical Reference Diagrams; Fig.10-13 Diagrams

EN 08
Technical Reference Diagrams
Fig.10 Fig.11
Fig.12
MOTOR UNIT A MOTOR UNIT B
MOTOR UNIT B MOTOR UNIT A
Fig.13
175mm
(min)
30mm to 45mm
155mm
(min)
85mm (min)
85mm (min)
2.8mm to 3.5mm
1800mm to 2500mm (max)
