Quectel EC25 Mini PCIe - Page 64

LTE Standard Module Series
EC25 Mini PCIe Hardware Design
EC25_Mini_PCIe_Hardware_Design 63 / 79
DCS1800 3DL/2UL @29.24dBm
245.0
mA
DCS1800 2DL/3UL @27.15dBm
337.0
mA
DCS1800 1DL/4UL @25.88dBm
427.0
mA
EDGE data
transfer
(GNSS OFF)
EGSM900 4DL/1UL PCL=8 @26.60dBm
170.0
mA
EGSM900 3DL/2UL PCL=8 @25.43dBm
205.0
mA
EGSM900 2DL/3UL PCL=8 @23.4dBm
280.0
mA
EGSM900 1DL/4UL PCL=8 @22.36dBm
348.0
mA
DCS1800 4DL/1UL PCL=2 @25.59dBm
136.0
mA
DCS1800 3DL/2UL PCL=2 @24.54dBm
225.0
mA
DCS1800 2DL/3UL PCL=2 @22.38dBm
300.0
mA
DCS1800 1DL/4UL PCL=2 @21.24dBm
379.0
mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B1 HSDPA @22.93dBm
504.0
mA
WCDMA B1 HSUPA @22.62dBm
512.0
mA
WCDMA B8 HSDPA @22.88dBm
562.0
mA
WCDMA B8 HSUPA @22.14dBm
535.0
mA
LTE data
transfer
(GNSS OFF)
LTE-FDD B1 @23.6dBm
664.0
mA
LTE-FDD B3 @23.67dBm
693.0
mA
LTE-FDD B7 @23.83dBm
800.0
mA
LTE-FDD B8 @23.82dBm
695.0
mA
LTE-FDD B20 @23.88dBm
690.0
mA
LTE-FDD B28A @23.43dBm
669.0
mA
LTE-TDD B38 @22.82dBm
438.0
mA
LTE-TDD B40 @23.43dBm
355.0
mA
LTE-TDD B41 @23.46dBm
451.0
mA
GSM
EGSM900 PCL=5 @33.25dBm
258.0
mA
