Quectel EC25 Mini PCIe - Page 66

LTE Standard Module Series
EC25 Mini PCIe Hardware Design
EC25_Mini_PCIe_Hardware_Design 65 / 79
Table 45: Current Consumption of EC25-MX Mini PCIe
WCDMA B5 HSDPA @22.02dBm
618.0
mA
WCDMA B5 HSUPA @22.10dBm
634.0
mA
LTE data
transfer
(GNSS OFF)
LTE-FDD B2 @23.01dBm
743.0
mA
LTE-FDD B4 @22.58dBm
816.0
mA
LTE-FDD B5 @23.2dBm
751.0
mA
LTE-FDD B12 @22.94dBm
825.0
mA
LTE-FDD B13 @23.18dBm
815.0
mA
LTE-FDD B14 @23.44dBm
849.0
mA
LTE-FDD B66 @23.2dBm
850.0
mA
LTE-FDD B71 @22.82dBm
788.0
mA
WCDMA voice
call
WCDMA B2 @23.27dBm
672.0
mA
WCDMA B4 @23.22dBm
663.0
mA
WCDMA B5 @23.02dBm
680.0
mA
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
Sleep state
AT+CFUN=0 (USB disconnected)
1.55
mA
WCDMA PF=64 (USB disconnected)
2.82
mA
WCDMA PF=64 (USB connected)
2.98
mA
WCDMA PF=128 (USB disconnected)
2.33
mA
WCDMA PF=256 (USB disconnected)
2.13
mA
WCDMA PF=512 (USB disconnected)
1.97
mA
LTE-FDD PF=32 (USB disconnected)
4.36
mA
LTE-FDD PF=64 (USB disconnected)
3.14
mA
LTE-FDD PF=64 (USB connected)
3.33
mA
