DCS1800 4DL/1UL @29.63dBm
236.0
mA
DCS1800 3DL/2UL @28.59dBm
343.0
mA
DCS1800 2DL/3UL @26.62dBm
413.0
mA
DCS1800 1DL/4UL @25.29dBm
498.0
mA
EDGE data
transfer
(GNSS OFF)
EGSM900 4DL/1UL @27.51dBm
234.0
mA
EGSM900 3DL/2UL @27.23dBm
372.0
mA
EGSM900 2DL/3UL @27.08dBm
501.0
mA
EGSM900 1DL/4UL @26.81dBm
628.0
mA
DCS1800 4DL/1UL @26.29dBm
199.0
mA
DCS1800 3DL/2UL @26.18dBm
309.0
mA
DCS1800 2DL/3UL @26.05dBm
415.0
mA
DCS1800 1DL/4UL @25.35dBm
503.0
mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B1 HSDPA @22.01dBm
755.0
mA
WCDMA B1 HSUPA @22.79dBm
776.0
mA
WCDMA B8 HSDPA @22.21dBm
670.6
mA
WCDMA B8 HSUPA @22.04dBm
692.6
mA
LTE data
transfer
(GNSS OFF)
LTE-FDD B1 @23.63dBm
918.7
mA
LTE-FDD B3 @22.78dBm
914.0
mA
LTE-FDD B7 @22.31dBm
985.2
mA
LTE-FDD B8 @23.35dBm
886.5
mA
LTE-FDD B20 @22.71dBm
909.1
mA
LTE-FDD B28A @21.79dBm
898.1
mA
LTE-TDD B38 @22.85dBm
587.8
mA
LTE-TDD B40 @22.96dBm
460.6
mA
LTE-TDD B41 @22.69dBm
571.2
mA
