6. The AGND pin of M95 R2.0 should be routed as single-ended to main ground when analog audio is
used in single-ended application. Otherwise, it can be connected to GND directly.
7. “*” means under development.
8.
1)
DTR pin can be used as SIM1_PRESENCE pin via AT command. For more details, please refer to
document [3].
9.
2)
When (U)SIM2 interface is used, DCD pin can be used as SIM2_RST pin. For more details, please
refer to document [5].
