HSPA/UMTS/GSM/GPRS Module Series
UG96&UG95&M95 R2.0 Compatible Design
UG96&UG95&M95 R2.0_Compatible_Design 29 / 42
RF_ANT
R1 0R
C1
NM
C2
NM
UG96/UG95/M95 R2.0
Figure 18: Reference Design of RF Interface
