Quectel M66 User Manual

GSM/GPRS/NB-IoT Module Series
BC68&M66 Compatible Design
BC68&M66_Compatible_Design 9 / 31
1.
1)
Within operation temperature range, the module is 3GPP compliant.
2.
2)
Within extended temperature range, the module remains the ability to establish and maintain a
voice, SMS, data transmission, emergency call, etc. There is no unrecoverable malfunction. There
are also no effects on radio spectrum and no harm to radio network. Only one or more parameters like
P
out
might reduce in their value and exceed the specified tolerances. When the temperature returns to
normal operating temperature levels, the module will meet 3GPP specifications again.
3. “*” means under development.
Two analog output channels
ADC
ADC*
Supported
RTC Backup
Not supported
Vnorm=2.8V
VI=1.5V~3.3V
PCM Interface
Not supported
Supported
Firmware Upgrade
UART, DFOTA
UART
NOTES

Quectel M66 Specifications

General

Category	GSM/GPRS Module
Frequency Bands	GSM 850/900/1800/1900 MHz
GPRS	Class 12
Operating Temperature	-40°C to +85°C
Voice Codec	HR, FR, EFR, AMR
GPRS Data Rate	Max 85.6 kbps (DL), Max 42.8 kbps (UL)
Interfaces	UART, ADC
Protocols	PPP, TCP/IP, UDP, FTP, HTTP
SIM Card	1.8V/3.0V
Certifications	CE, GCF, FCC, PTCRB, IC
Supply Voltage	3.3V ~ 4.5V (Typ. 3.8V)
Antenna	External Antenna
