Quest Controls 600 User Manual

Rev 3.1 01/11/23 - 28 - Model 600 User Guide
Function Code
Register
Description
Read/
Write
Type Default
Notes
Non-volatile
5 HVAC 2 Econ Status RO bit N/A 0 = off and 1 =on N
6
Smoke Detector Status
RO
bit
N/A
0 = off and 1 =on based on Reg
1205
7
Hydrogen Sensor Status
RO
bit
N/A
0 = off and 1 =on based on Reg
1206
8
Gen Run Status
RO
bit
N/A
0 = off and 1 =on based on Reg
1207
Digital Outputs
Read coil/output
(FC1)
0
HVAC 1 Fan (G)
RO bit N/A 0 off, 1 on N
1
HVAC 1 Cooling (Y1)
RO bit N/A 0 off, 1 on N
2
HVAC 1 Force Mech Cooling (2)
RO
bit
N/A
0 off, 1 on
N
3
HVAC 1 Heating (W)
RO bit N/A 0 off, 1 on N
4
HVAC 1 Cool2/Heat Pump (Y2/O)
RO
bit
N/A
0 off, 1 on
N
5
HVAC 1 Emerg Ven Mode (MAR)
RO bit N/A 0 off, 1 on N
6
HVAC 2 Fan (G)
RO
bit
N/A
0 off, 1 on
N
7
HVAC 2 Cooling (Y1)
RO bit N/A 0 off, 1 on N
8
HVAC 2 Force Mech Cooling (2)
RO
bit
N/A
0 off, 1 on
N
9
HVAC 2 Heating (W)
RO bit N/A 0 off, 1 on N
10
HVAC 2 Cool2/Heat Pump (Y2/O)
RO
bit
N/A
0 off, 1 on
N
11
HVAC 2 Emerg Ven Mode (MAR)
RO bit N/A 0 off, 1 on N
12
HVAC Lockout Alarm
RO bit N/A
1 off, 0 on. Output energized when
not in alarm.
N
13
High Building Temp L2 Alarm
RO bit N/A
1 off, 0 on. Output energized when
not in alarm.
N
14
High Building Temp L1 Alarm
RO bit N/A
1 off, 0 on. Output energized when
not in alarm.
N
15
Low Building Temp Alarm
RO bit N/A
1 off, 0 on. Output energized when
not in alarm.
N
16
Smoke Alarm
RO bit N/A
1 off, 0 on. Output energized when
not in alarm.
N
