WARNING: Allowing yellow wire to contact red or white wire
will destroy the transformer.
Dehumidifier on : Connect yellow and blue wires.
Fan only on : Connect yellow and green (or brown) wires.
Accessory power : 24volt AC power supply available for HVAC accessories between yellow and
white(and/or red) wire. Red and white wires are common with each other.
Quest DEH 3000 dehumidification & ventilation control
YELLOW
BLUE
GREEN or BROWN
WHITE
Internal Connections
OPTIONAL
DAMPER
24 VAC
DMP COMP FAN
DEH3000 P/N: 4027370
DEH3000R (remote) P/N: 4028531
Model: DEH 3000
DEH 3000R (remote)
Operating Voltage: 24 VAC
Max Current
DMP, COMP, FAN: 1 AMP each
Humidity Range/Accuracy: 10 – 95% RH, ± 5%
Auxillary Relay Capacity: 5 Amps, 24VAC
Temp Range/Accuracy: 30°-90°F, 2%
Size: 4.95"L x 1.06"W x 4.19"H
Major Operations
• Digital control of Relative Humidity (Digital Set-Point)
• Fan/Filter Operation
• Programmable Ventilation Timer
• Large, easy-to-read backlit LCD display
• Easy interaction with air handler fan (Interlock/Lockout)
• High Temperature Cut-Out
• Dryout Cycle Timer
• Auto Reboot
• Remote Sensor (DEH 3000R Only)
To order call Therma-Stor at
1-800-533-7533
DEH 3000/DEH 3000R
DEH 3000/DEH 3000
R
Part No. 4027370
Part No. 4028531
6. Optional Dehumidifier & Ventilation System Controller
When used with Quest 215 Dual Whole Structure Ventilating Dehumidifiers, the DEH 3000/3000R allows end-
users the ability to monitor and control relative humidity levels in their structure.

Quest Engineering 215 Dual Specifications

General

Brand	Quest Engineering
Model	215 Dual
Category	Dehumidifier
Language	English
