PR-120 / PR-240
Specifications
Specifications
PR-120 PR-240
Input Sensitivity for full
output at maximum gain
Balanced Microphone Channels -50dB ± 3dB
Balanced Line Channels -22dB ± 3dB
Balanced Remote Microphone Station -50dB ± 3dB
Balanced Telephone Paging -21dB ± 3dB
Unbalanced Link-In -17dB ± 3dB
Unbalanced Amp-In 0dB ± 3dB
Frequency Response at 1 watt from speaker out tap.100Hz~10kHz +1.5dB / -3dB
Graphic Equalizer
125Hz,250Hz,500Hz,1kHz,2kHz,4kHz,8kHz ±12dB ±3dB
Signal to Noise Ratio at rated power output Better than 90dB
Crosstalk at all control maximum -70dB at 1kHz
Rated Output Power at THD 0.5% 120Watts 240Watts
Total Harmonic Distortion(THD) at 1kHz rated power Less than 0.5%
Phantom Power 15VDC
Power Band Width at 1kHz from speaker out tap
80Hz~15kHz with less than 0.5%
THD
DC Output Offset Less than ±3mV
Operating Temperature/Humidity at non-condensing 0°~40°C at 95% humidity
Output Voltage and
Impedance
4Ω 22V 31V
25V 5.2Ω 2.6Ω
70V 42Ω 21Ω
100V 83Ω 42Ω
Construction
Cooling Convection Cooled
Dimensions (Width/Height/Depth) 420(W) x 88(H) x 320(D) mm
Net Weight 9.76 kg 9.53 kg
Necessary modications are carried out without notice
