Quick MILL Monza Deluxe - Diagrams; Front; Inside; Back

Monza Deluxe Super Automatic Espresso Machine
4
4
FRONT
INSIDE
BACK
1. Bean Hopper
2. Display
3. Touchpad
4. Water Reservoir
5. Drip Tray
6. Cup Warming Tray
7. Steam/Hot Water Wand
8. Grounds Drawer
9. Cup Pedestal
10. Raised Platform (optional)
1. Grinder Adjustment
2. Milk Frother
3. Piston Assembly
4. Piston O-Ring
5. Brew Chamber Cover
1. Reservoir/Water Line Switch*
2. Main Power Switch
3. Direct Connect Fitting
4. Power Cord Receptacle
*Tanica = Water Reservoir Mode
Rete = Plumbed Water Line Mode
DIAGRAMS
