AL3 Series
EN
QUICK AL3Series INSTALLATION AND USER’S MANUAL - REV000A
16
Refer to the exploded drawing on page.14
CODE DESCRIPTION NUMB. OF PARTS
FVSSRM100000A00 OSP INSERT MANUAL ANCHOR WEIGHING 1000W 5 - 9
FVSSGMSDP300000 OSP DRUM BUSH “SERIES AL3” 7 - 8
FVSSMSE10AL0A00 OSP WINDLASS DRUM 1000W AL 6
FVSSMSE10000A03 OSP WINDLASS DRUM 1000W COMPLETE R03 6 - 7 - 8
FVSSTAL10D08A00 OSP TOP ALEPH 7/10/1500W D 8MM-5/16”
da 6 a 8 - da 10 a 20 - da 22 a 41 - da 46 a 48
FVSSTAL10D10A00 OSP TOP ALEPH 7/10/1500W D 10MM-3/8”
FVSSAAL1000DA00 OSP SHAFT KIT AL 1000 D da 16 a 20 - 22 - 23
FVSSAAL10000A00 OSP SHAFT KIT AL 1000 da 16 a 21 - 23
FVSSLVSP00R1A00 OSP CURVED WINDLASS LEVER R01 1
FVSSGMSDFRAL000 OSP OSP CLUTCH BUSH SERIES AL 2 - 3
FVSSCPBBAL00A00 OPS GYPSY COVER ALEPH 4 - 5
FVSSTAL10008A00 OSP TOP ALEPH 7/10/1500W 8MM-5/16”
da 6 a 8 - da 10 a 21 - da 23 a 41 - da 46 a 48
FVSSTAL10010A00 OSP TOP ALEPH 7/10/1500W 10MM-3/8”
FVSSTCAL0000A00 OSP PRESSURE LEVER KIT ALEPH 27 - da 29 a 32
FVSSCPSCAL00A00 OSP CHAIN GUIDE COVER KIT AL 24 - 25 - 26 - 28
FVSSB100851TA00 OSP GYPSY 1000W 8MM-5/16” AT/AL
10 - 12 - 14
FVSSB101038TA00 OSP GYPSY 1000W 10MM-3/8” AT/AL
FVSSCFANHC00A00 OSP CLUTCH CONES AT/HC/AL/DP3 11 - 13
FVSSBLBBDN00A00 OSP KIT GYPSY LOCK DN/AL da 33 a 37
FVSSBAL10C00A00 OSP WINDLASS BASE 1000W SERIES AL COMP da 24 a 41 - da 46 a 48
FVSSMR10TG50B00 OSP GEARBOX 1000W WINDLASS QUICK R1 42 - 44 - da 46 a 51
FVSSMR15TG70A00 OSP GEARBOX 1500W WINDLASS QUICK TG70 43 - da 45 a 51
FVSSR0712Q00B00 OSP MOTORGEARBOX 700W 12V QUICK R1
42 - 44 - da 46 a 60
FVSSR1012Q00B00 OSP MOTORGEARBOX 1000W 12V QUICK R1
FVSSR0724Q00B00 OSP MOTORGEARBOX 700W 24V QUICK R1
FVSSR1024Q00B00 OSP MOTORGEARBOX 1000W 24V QUICK R1
FVSSR1512Q00A00 OSP MOTORGEARBOX 1500W 12V QUICK
43 - 45 - da 46 a 60
FVSSR1524Q00A00 OSP MOTORGEARBOX 1500W 24V QUICK
FVSSM0712000A00 OSP WINDLASS MOTOR 700W 12V
da 49 a 60
FVSSM0724000A00 OSP WINDLASS MOTOR 700W 24V
FVSSM1012000A00 OSP WINDLASS MOTOR 1000W 12V
FVSSM1024000A00 OSP WINDLASS MOTOR 1000W 24V
FVSSM1512000A00 OSP WINDLASS MOTOR 1500W 12V
da 49 a 60
FVSSM1524000A00 OSP WINDLASS MOTOR 1500W 24V
10 - Spare parts
