Quick AL3 Series User Manual

AL3 Series
EN
17
MANUALE D’INSTALLAZIONE ED USO QUICK AL3Series - REV000A
A
B
C
F
E
G
H
D
AL3Series
(-/D)
AL3 P
700W
AL3 P
1000W
AL3
1500W
A 102 (4” 1⁄64)
B DRUM 169 (6” 21⁄32)
C 155,4 (6 1/8) 170,4 (6” 45/64)
D 239 (9” 13/32)
E 141,5 (5” 27/32) 161,5 (6” 23/64)
F 340 (13” 25⁄64) 355 (13” 31/32) 385 (15” 5/32)
G 98 (3” 55/64)
H 81 (3” 3/16)

Quick AL3 Series Specifications

General

Brand	Quick
Model	AL3 Series
Category	Boating Equipment
Language	English
