MAINTENANCE
WARNING:
make sure the electrical power to the motor
is switched off when working manually on the windlass.
Carefully remove the chain from the gypsy or the rope from
the drum.
Quick
®
windlasses are manufactured with materials resistant to
marine environments. In any case, any salt deposits on the outside
must be removed periodically to avoid corrosion and damage to
the equipment. The parts where salt may have built up should be
washed thoroughly with fresh water.
Once a year, the drum and the gypsy are to be taken apart as fol-
lows:
DRUM VERSION
Use the handle (1) to loosen the bush (2); pull off the drum (3) and
the top clutch cone (5); loosen the fixing screws (20) of the rope/
chain stripper (21) and remove it. Pull off the gypsy (6).
NO-DRUM VERSION
Use the handle (1) to remove the gypsy cover (4); remove the top
clutch cone (5); loosen the fixing screws (20) of the rope/chain strip-
per (21) and remove it. Pull off the gypsy (6).
Clean all the parts removed to avoid corrosion, and grease the shaft
thread (11 or 12) and the gypsy (6) where the clutch cones rest (5).
Clean all the parts removed to avoid corrosion, and grease the shaft
thread (11 or 12) and the gypsy (6) where the clutch cones rest (5).
Remove any oxide deposits from the terminals of the electric motor
and the reversing contactor unit; grease them.
POS. DESCRIPTION CODE
10 Bearing MBJ160040000
11 Shaft DP1 MSASDP100R00
12 Shaft DP1 D MSASDP1D0R00
13 Key 6*6*25 MBH060625X00
14 Key 6*6*50 MBH060650X00
15 Oil seal 20*35*7mm PGPRL2035700
16 Chain guide cover DP1 PDGCDP100000
17 Plastic chain pipe DP1 PDPSSDP10R01
18 Screw M 4*30 stainless steel MBV0430MXVEP
19 Screw M 5*30 stainless steel MBV0530MXCE0
20 Screw M 5*40 stainless steel MBV0540MXCE0
21 Chian stripper DP1 stainless steel SPMSNDP10000
22 Plug 4*22 stainless steel MBSC04022A00
23 Screw M 6*12 stainless steel MBV0612MXTSC
24 Cover base DP1 stainless steel SPMSGB0DP1X0
25 Insert plastic cover DP1 PDNC0DP10000
26 Nut M4 MBD04MXEN000
27 Nut M5 MBD05MXEN000
28
Round base DP1
anodized aluminium
SGMSC0DP1A00
29 Gasket / jig PGBSDP100000
30 Sensor KNREEDCL0000
31 Stud MBP080608X00
32 Gearbox flange gasket
300/500W
PGFLRDTG4000
33A Gearbox 500W Quick series SLMR05TG4000
33B Gearbox “Hi Speed” 500W
Quick series SLMR05TG40HS
34 Washer MBR08X000000
35 Spring washer MBR08XDE0000
36 Nut MBD08MXEN000
37 Screw MBV0516MXE00
38 Geared motor seal PGBMR0400000
39 Key MBH040415F00
40A Electric motor 300W 12V EMF031200000
40B Electric motor 500W 12V EMF051200000
40C Electric motor 500W 24V EMF052400000
41 Flange gasket PGGPMFN04000
42
Motor casing watertight 300/500W
PCCCPM040000
43
Poles gasket
electric motor 300/500W
PGGPMPM04000
44 Bottom protec cover
electric motor 300/500W
PCCPPMFN0400
45 Screw MBV03916AXCC
