Quick DP1 312 User Manual

44
DP1 300/500W - REV001B
44
MAIN CONNECTION DIAGRAM
QUICK
®
WINDLASS
WATERTIGHT HAND
HELD
CHAIN-COUNTER
MOD. CHC 1102 M
MULTI-PURPOSE
WATERTIGH
HAND HELD
REMOTE
CONTROL
MOD. HRC 1002
WATERTIGHT PANEL
CHAIN-COUNTER
MOD. CHC 1202 M
WINDLASSES
CONTROL BOARD
MOD. 800
L = L1 + L2 + L3 + L4 + L5
SENSOR
MOTOR
FUSE
4A (12V) 2A (24V)
BATTERY
HYDRAULIC
MAGNETIC
CIRCUIT BREAKER
(see table on page
4/12/20/28/36)
C
A2
A1
REVERSING CONTACTOR UNITS MOD. T6415-12 (12V) MOD. T6415-24 (24V)
L1
L2
L3
BLUE
BROWN
BLACK
BLUE
BROWN
BLACK
UP
SENSOR
DOWN
-
+
GREY
RED
GREEN
BROWN
WHITE
BLUE
BLACK
BLUE
BROWN
BLACK
L4
150
CAN H
CAN L
CAN H
CAN L
CAN L
CAN H
L5
MOD. 900/D
DOWN
FOOT SWITCH
MOD. 900/U
UP
UP
DOWN
-
+
RADIO RECEIVER RRC MOD. R02 (2CH)
