Quick ECS Series

11
ECS - REV003A
GB
QUICK
®
RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
(1)
Typical values.
(2)
Total maximum current divided over output points.
MAINTENANCE
The charge separator needs no particular maintenance.
To ensure optimum performance from the device, once a year check the cables and the electrical connections.
TECHNICAL DATA
MAINTENANCE - TECHNICAL DATA
MODEL
ECS 162 ECS 163 ECS 222 ECS 223
INPUT CHARACTERISTICS
Input voltage
5 ÷ 31 Vdc
Loss of voltage
(1)
< 0,2 Vdc (0,04 Vdc @ 20A)
OUTPUT CHARACTERISTICS
Number of outputs 2323
Battery charger current
(2)
120A 180A
Charge current from alternator
(2)
160A 220A
PROTECTION
Reverse polarity Yes
AMBIENT CHARACTERISTICS
Operating temperature
from -20 to +70 °C
Cooling
Natural
GENERAL CHARACTERISTICS
Dimensions (W x H x D)
195 x 68 x 135 mm
Weight 1200 g 1250 g 1200 g 1250 g
